Stranded Loose Tube Armored Cable

China Stranded Loose Tube Armored Cable supplier

Large Image :  Stranded Loose Tube Armored Cable

Product Details:

Place of Origin: Ningbo of China
Brand Name: EVERTOPCOMMS

Payment & Shipping Terms:

Payment Terms: TT/LC/Western Union
Contact Now
Detailed Product Description

Stranded Loose Tube Armored Cable



Characteristic

Good mechanical and temperature

performance.

Good crush resistance, waterblocking

and flexibility



Geometrical Characteristics

Cable Type

2-60

Cable Diameter(mm)

13.5

Cable Weight(kg/km)

235

Mechanical Characteristics



Max Load(N)

 Long Term

600

 Short Term

1500



Crush Resistance(N/100mm)

 Long Term

300

Short Term

1000



Bending Radius(MM)

 Dynamic

102

 Static

204

Fiber

Fiber Type(core/cladding dimension)

8.3/125, 50/125, 62.5/125

Transmission Characteristics



 SMF

50/125

62.5/125



1310/1550(nm)

850/1300(nm)

850/1300(nm)

Max Attenuation(dB/km)

0.45/0.30

3.5/1.5

3.5/1.5

AVG. Attenuation(dB/km)

0.40/0.25

3.0/1.0

3.0/1.0

Min Bandwidth(MHz·km)

——

400/400

160/500

Environmental Characteristics

Storage Operating Temperature

-40℃~+70℃
