SC/APC Connectors, ABS Box Type1*4 Single Mode Fiber Optic Splitters
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Fiber Optic Splitters | Material: | PVC |
|---|---|---|---|
| Name: | 1*4 2.0 Mm SC/APC Connectors, ABS Box Type Fiber Optic Splitters | Connector: | SC/APC |
| Application: | Data Communications | Operating Temperature (°C): | -40~+85 |
| Operating Wavelength(nm): | 1260~1650 | Type: | 1*4 |
| Color: | Yellow Or Any Other Color |
Product Description
1*4 2.0 mm
1.5mt SC/APC Connectors, ABS Box type fiber optic splitters
PLC Splitter is a kind of planar waveguide integrated optical device, it can be 1260nm ~ 1650nm such a wide range of wavelengths of light power reservation in realization, the distribution of wavelength range covers EPON technology used1310nm, 1490nm and 1550nm three wavelengths. Especially suitable for EPON Ethernet passive optical network access technology FTTP fiber network system, broadband passive optical distributor (POS) use.
Performance Specifications: | ||||||||||||||
1×N PLC Splitter (Measured at room temperature include connector data) | ||||||||||||||
TYPE | 1*2 | 1*4 | 1*8 | 1*16 | 1*32 | 1*64 | ||||||||
Fiber Type | G657A or customer Request | |||||||||||||
Operating Wavelength(nm) | 1260～1650 nm | |||||||||||||
Insertion Loss(dB) | Max (include connector) | 4.2 | 7.5 | 11 | 14 | 17.4 | 20.5 | |||||||
Max(no connector) | 3.7 | 7.2 | 10.5 | 13.2 | 16.9 | 19.5 | ||||||||
Uniformity Loss(dB) | Max | 0.6 | 0.6 | 0.8 | 1.2 | 1.5 | 1.8 | |||||||
Polariation Dependent Loss(dB) | Max | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.5 | |||||||
Return Loss (dB) | UPC:50 APC:55 | |||||||||||||
Operating Temperature (°C) | -40～+85 | |||||||||||||
2×N PLC Splitter (Measured at room temperature include connector data) | ||||||||||||||
TYPE | 2*2 | 2*4 | 2*8 | 2*16 | 2*32 | 2*64 | ||||||||
Fiber Type | G657A or customer Reques | |||||||||||||
Operating Wavelength(nm) | 1260～1650nm | |||||||||||||
Insertion Loss(dB) | Max(include connector) | 4.4 | 7.8 | 10.9 | 14.3 | 17.2 | 20.5 | |||||||
Uniformity Loss(dB) | Max | 0.4 | 0.8 | 0.8 | 1 | 1.5 | 1.8 | |||||||
Polariation Dependent loss(dB) | Max | 0.2 | 0.2 | 0.2 | 0.3 | 0.3 | 0.4 | |||||||
Return Loss (dB) | UPC:50 APC:55 | |||||||||||||
Operating Temperature (°C) | -40～+85 | |||||||||||||
Note:Connector type:SC,FC,LC,ST,etc, PC,UPC,APC are be ok.as request. | ||||||||||||||
PLC MINI TYPE AS STRUCTION PICTURE | ||||||||||||||||
ORDER INFORMATION | ||||||||||||||||
Wavelength (nm) | Port | Input Fiber Length | Output Fiber Length | Input Fiber Type | Output Fiber Type | Fiber Standard | Input Connector | Output Connector | ||||||||
PLC=1260-1650 | 102=1*2 104=1*4 108=1*8 116=1*16 132=1*32 164=1*64 202=2*2 204=2*4 208=2*8 216=2*16 232=2*32 264=2*64 | 1=1M 2=2M 3=Customized | 1=1M 2=2M 3=Customized | 1=250um bare fiber 2=900um loose tube 3=900um tight tube | 1=250um bare fiber 2=250um ribbon fiber | 1=G652 2=G657A 3=G657B | 0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=LC/PC 6=ST | 0=None 1=FC/APC 2=FC/PC 3=SC/APC 4=SC/PC 5=LC/PC 6=ST | ||||||||
Application:
• Data Communications
• Lan and CATV System
Feature:
♦ Low insertion loss
♦ Low PDL
♦ High return loss
Compliance:
- Telcordia GR-1221-CORE-1999
- RoHS
