Duplex Multimode Flat Aqua Jacket OM3 LSZH Optical Fiber Cable
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Fiber Optic Cable, OM3 | Number Of Conductors: | 2 |
|---|---|---|---|
| Name: | 6 Core Fiber Indoor OM3 Black Outer Jacket Fiber Optic Cable | Jacket Material: | LSZH |
| Jacket Color: | Aqua | Fiber Count: | 2 |
| Operating Temperature: | -40°-70°C | Strength Member: | Kevlar |
| Application: | Indoor Optical Fiber Cable |
Product Description
Duplex multimode Flat Aqua jacket OM3 LSZH optical fiber Cable
The indoor optical fiber cables are laid in buildings. And widely used in communication equipment, computers,switches,and users in building.
Fiber Parameters: | ||||||||
No. | Item | Unit | Specification | |||||
10G-300 | ||||||||
1 | Core Diameter | μm | 50.0±2.0 | |||||
2 | Cladding Diameter | μm | 124.8±1.0 | |||||
3 | Core Non-Circularity | % | ≤5.0 | |||||
4 | Cladding Non-Circularity | % | ≤1.0 | |||||
5 | Core-Cladding Concentricity Error | μm | ≤1.0 | |||||
6 | Coating Diameter | μm | 245±7 | |||||
7 | Coating Non-Circularity | % | ≤6.0 | |||||
8 | Cladding-Coating Concentricity Error | μm | ≤12.0 | |||||
8 | Bandwidth(min.) | 850nm | MHz·km | ≥1500 | ||||
9 | 1300nm | MHz·km | ≥500 | |||||
10 | Attenuation Coefficient | 850nm | dB/km | ≤3.0 | ||||
1300nm | dB/km | ≤1.0 | ||||||
Cable Parameters: | ||||
Items | Specifications | |||
Fiber Count | 2 | |||
Optical Fiber | Dimension | 245±5μm | ||
Color | Natural | |||
Tight-buffered Fiber | Dimension | 850±50μm | ||
Color | White & yellow | |||
Material | PVC | |||
Strength Member | Kevlar | |||
Material | Steel | |||
Outer Jacket | Dimension | (2.850±0.10)mm×(5.80±0.20)mm | ||
Material | LSZH | |||
Color | Aqua | |||
Mechanical and Environmental Characteristics: | ||||
Items | Unite | Specifications | ||
Tension(Long Term) | N | 80 | ||
Tension(Short Term) | N | 150 | ||
Crush(Long Term) | N/10cm | 100 | ||
Crush(Short Term) | N/10cm | 500 | ||
Min. Bend Radius(Dynamic) | mm | 20D | ||
Min. Bend Radius(Static) | mm | 10D | ||
Installation Temperature | ℃ | -10～+50 | ||
Operating Temperature | ℃ | -20～+60 | ||
Storage Temperature | ℃ | -20～+60 | ||
Applications:
- wide area network
- active device termination
- telecommunication network
