Data Processing Network Single Core Indoor LSZH Jacket SM Fiber Optic Cable
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Fiber Optic Cable | Jacket Color: | Yellow |
|---|---|---|---|
| Jacket Material: | LSZH | Name: | LSZH Single Core Indoor Yellow Jacket SM Fiber Optic Cable |
| Application: | Indoor | Strength Member: | Kevlar |
| Operating Temperature: | -20°C-+60°C |
Product Description
LSZH Single Core Indoor yellow jacket SM fiber optic cable
Fiber Parameters: | ||||||||
No. | Items | Unit | Specification | |||||
G.657A1 | ||||||||
1 | Mode Field Diameter | 1310nm | μm | 9.0±0.4 | ||||
1550nm | μm | 10.1±0.5 | ||||||
2 | Cladding Diameter | μm | 124.8±0.7 | |||||
3 | Cladding Non-Circularity | % | ≤0.7 | |||||
4 | Core-Cladding Concentricity Error | μm | ≤0.5 | |||||
5 | Coating Diameter | μm | 245±5 | |||||
6 | Coating Non-Circularity | % | ≤6.0 | |||||
7 | Cladding-Coating Concentricity Error | μm | ≤12.0 | |||||
8 | Cable Cutoff Wavelength | nm | λcc≤1260 | |||||
9 | 1310nm | dB/km | ≤0.4 | |||||
1550nm | dB/km | ≤0.3 | ||||||
10 | 1turn×10mm radius @1550nm | dB | ≤0.75 | |||||
1turn×10mm radius @1625nm | dB | ≤1.5 | ||||||
Cable Parameters: | ||||
Items | Specifications | |||
Fiber Count | 1 | |||
Tight-buffered Fiber | Dimension | 900±50μm | ||
Color | White | |||
Material | LSZH | |||
Self-Supporting Member | Dimension | 1.2mm | ||
Material | Galvanized Steel Wire | |||
Color | Natural | |||
Strength Member | Kevlar | |||
Phosphatized Steel Wire | ||||
Outer Jacket | Dimension | (2.85±0.1)mm | ||
Material | LSZH | |||
Color | Yellow | |||
Mechanical and Environmental Characteristics: | ||||
Items | Unit | Specifications | ||
Tension(Long Term) | N | 80 | ||
Tension(Short Term) | N | 160 | ||
Crush(Long Term) | N/10cm | 100 | ||
Crush(Short Term) | N/10cm | 500 | ||
Min. Bend Radius(Dynamic) | mm | 20D | ||
Min. Bend Radius(Static) | mm | 10D | ||
Installation Temperature | ℃ | -10～+60 | ||
Operating Temperature | ℃ | -20～+60 | ||
Storage Temperature | ℃ | -20～+60 | ||
Applications:
- Instrument
- Premise installations
- Data processing network.
