8 Core Waterproof Fiber Optic Terminal Box, Htth, White or Black Plastic
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Type: | Fiber Optic Distribution Box |
|---|
Description
This box is used as a termination point for the feeder
cable to connect with drop cable in FTTX communication
network system.
It intergtates fiber splicing, splitting, distribution, storage
and cable connection in one unit. Meanwhile, it provides
solid protection and management for the FTTX network
building
.
Features
1,Total enclosed structure.
2, Material: ABS, wet
-
proof, water
-
proof,dust proof,anti
-
aging,
rosh.
3, Clamping for feeder cable and drop cable, fiber splicing, fixation,
storage distribution ... etc all in one.
4 , Cable, pigtails, patch cords are running through own path without
disturbing each other, cassette type SC adaptor .installation, easy
maintenance.
5, Distribution panel can be flipped up, feeder cable can be placed in a
cup
-
joint way, easy for maintenance and installation.
6 , Box can be installed by the way of wall
-
mounted or poled
mounted,suitable for both indoor and outdoor uses.
Configuration
Material Size Max Capacity Nos of Adaptor Weight Ports
Strengthen
ABS
A
*
B
*
C(mm)
230
*
195
*
55
Splice 8 Fibers
(1trays,8 core/tray)
PLC Splitter
1pcs of 1x8
8 pcs of SC(max) 0.55kg 3 in 8 out
Applications
Wall mounting and pole mounting installtion
FTTH pre
-
installation and filed installation
5
-
10mm cable ports suitable for 2x3mm indoor FTTH drop cable and outdoor figure 8 FTTH self
-
supporting drop cable
Standard Accessories
Screw: 4mm
*
40mm 4pcs
Expension bolt: M6 4pcs
Cable tie:3mm
*
10mm 6pcs
Heat
-
shrink sleeve:1.0mm
*
3mm
*
60mm 8pcs
Hose clamps:3pcs
