Flat Fiber Ribbon Cable
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
Flat Fiber Ribbon Cable
1.Characteristic
.Fiber ribbon, aramid yarn, flame-retardant jacket
.Suited to SM fiber
2.Geometrical Characteristics
|
Cable Type |
4 |
6 |
8 |
12 |
|
Cable Diameter(mm) |
2.4×3.3 |
2.4×4.0 |
2.4×4.5 |
2.4×5.0 |
|
Cable Weight(kg/km) |
4.5 |
4.8 |
5.2 |
5.6 |
|
Coloring Fiber Diameter(μm) |
260±5 |
|||
3.Mechanical Characteristics
|
Max Load(N) |
Long Term |
60 |
|
Short Term |
100 |
|
|
Bending Radius(CM) |
Dynamic |
60 |
|
Static |
30 |
4.Fiber
|
Fiber Type(core/cladding dimension) |
8.3/125 |
5.Transmission Characteristics
|
|
SMF |
|
|
1310/1550(nm) |
|
Max Attenuation(dB/km) |
0.45/0.30 |
|
AVG. Attenuation(dB/km) |
0.40/0.25 |
|
Min Bandwidth(MHz·km) |
---- |
6.Environmental Characteristics
|
Storage Operating Temperature) |
-20℃～+60℃ |
