CAT5Ee UTP 24 PORT PATCH PANEL

I'm Online Chat Now

CAT5Ee UTP 24 PORT PATCH PANEL

China CAT5Ee UTP  24 PORT  PATCH PANEL supplier

Large Image :  CAT5Ee UTP 24 PORT PATCH PANEL

Product Details:

Place of Origin: CHINA
Model Number: CAT5Ee UTP 24 PORT PATCH PANEL

Payment & Shipping Terms:

Minimum Order Quantity: 10
Contact Now
Detailed Product Description

cat 5e utp
cat5e  12 port 24 port rj45 patch panel cat5e jack panel
Meet TIA/EIA-568-A and TIA/EIA-568-B Category 5E requirements.
Meet TIA/EIA TSB-40
Meet ISO/IEC Generic Cabling Standard 11801
Meet CENELEC Generic Cabling Standard EN50173
Angle: 90 Degree
Termination: 110, KRONE,DUALTypes (3 types)
Electrical:
According to UL 1863
Current rating: 1.5 Amp Max.
Voltage rating: 150 Volts
Contact resistance: 20 m-ohm
Insulation Resistance: 500M-ohm
Dielectric Withstand Voltage: 1000 V AC RMS, 60Hz 1min
Materials:
Housing: PC UL94V-0
IDC: PC UL94V-0, Accept 22-26 AWG Solid Wire.
PCB: FR4 1.6mm(0.04") thickness, 2 layers
Contact: PC Ul94V-0, 0.45mm(0.018") Diameter Phosphor bronze with 3 u" to 50 u" Gold plating on contact area.
